Surpass Hobby 4068 Brushless Motor with 150A ESC Combo

Surpass Hobby 4068 Brushless Motor with 150A ESC Combo

VIEW ALL REVIEWS

R 2,790.00

Item Brand:Surpass HobbyItem Number:4076+150AItem Name:Motor +esc setMaterial:Metal and plasticColor:As the picture shownThe Size of the Motor:Length 76mm,diameter 40mm,shaft diameter is 5mm,length of extended shaft is 18mmThe Size of the ESC:60*45*45mmThe Weight of the Motor/ESC:About 368g/148gRecommendating...

Quantity:

- +

Ask a Question

FAQ

Guaranteed safe checkout:

Orders ship same day if ordered before 14h00

Description

Item Brand:Surpass Hobby
Item Number:4076+150A
Item Name:Motor +esc set
Material:Metal and plastic
Color:As the picture shown
The Size of the Motor:Length 76mm,diameter 40mm,shaft diameter is 5mm,length of extended shaft is 18mm
The Size of the ESC:60*45*45mm
The Weight of the Motor/ESC:About 368g/148g
Recommendating Program Card:product id:1057127
Fit For:1/8 rc car vehicles models

The Specification of the Motor:

KV:2000KV
Watts:2800
Max Voltage:<21V
Max Amps:135A
Rotor Poles:4
IO:2.3A
Resistance:0.0079
Max RPM:50000
Connector:4.0mm gold

The Specification of the ESC:

Cont.Current:150A
Burst Current:720A
Motor Type:Sensorless Brushless Motor
For 4s Lipo or 12 cells NiMH
1.On-road 42-size or smaller motor with the kv <3000
2.Off-road/monster 42-size or smaller motor with the kv <2500
For 6s lipo or 18 cells NiMH
